Features
•HS-6800 with 8.0mega ,
•A3, A4 Paper
•Line Resolution≥1000
•Gooseneck Design, Shooting any angle
•VGA/HDMI/USB Interface
•Built-in MIC
•1080P@30fps H.264 recording
•One key digital interconnection, fast saving by SD Card
Technical Parameters
Model | HS6800 |
Total Pixel | 8.0 mega (3264x2448) |
Frame Rate | 30fps(Max) |
Zoom | 2.5x no-loss/16x digital/10x mechanical |
Focus | Auto/ Manual |
Shooting Area | A3 (297*420mm) |
VGA Input Resolution | XGA,SXGA,720P,1080P |
Picture Output | 8.0 mega |
Recording Output | 1080p@30fps(max) |
USB Output | 3840x2160@8fps/1920x1080@30fps |
Picture Format | JPEG |
Record Format | MP4,Video H264,Audio AAC |
Image Adjustment | Brightness,Red ,Blue,etc |
Image Function | Negative,positive,freeze;minor, noise reduction,black/color,text increase,etc |
OSD | Yes |
Assistant Light | Yes( 1w LED) |
Standby VGA-in-use | Yes |
Wake up on Standby | Yes |
One Key Switch | Yes |
One key Digital Interconnection | Support SD Card fast exchange between Storage medium and U-disc |
Hardware Program Upgrade | Support |
Boot screen replacement | Support |
VGA | Input *1, Output *1 |
HDMI | Output*1 |
USB2.0 | *1 |
SD Card | Yes |
MIC | Yes |
Button | Yes(Waterproof membrane) |
Infrared Control | Yes |
Security Lock | Yes |
Power | DC 5V |
Bottom Size | 145*130mm |
Net Weight | 1.6(kg) |
